Manual Knee Mills MX-6HG

Short Description:

TAJANE manual knee milling cutter. A three-axis digital readout and a mechanical feed are installed. Hardened and ground rectangular guides contribute to machine rigidity for manual knee mills, and integral worms and gears allow precise angular positioning. Parts processing can realize high-speed, high-precision and high-efficiency functions.components.


Product Detail

Product Parameters

Video

Product Tags

MX-6HG manual knee milling machine is equipped with a 5HP heavy-duty motor. The X table can move up to 1000mm. The bed guide rail adopts a high-strength short double-sided structure to meet the rigidity requirements of processing. The lubricating device adopts a fully automatic electronic oil pump to precisely control the oil output. , the manual knee milling machine is widely used in the processing needs of complex parts and mold parts

Do you need such a milling machine?

5HG_04

Taiwan's original drawings manufacturing process

1
21
3

Mihanna Casting Technology

Elimination of internal stress

Tempering heat treatment

62
5
4

Precision machining

Lifting table processing

Lathe processing

7
8
9

Cantilever machining

High frequency quenching

Fine carving

Taiwan's original boutique parts, the only guarantee of the quality of precision

10
11
X.Y
ICO_r3_c1_01

Milling machine accessories meet different processing needs

15pic

15pic RNT40Chuck group

►φ03/4/5/6/8
►φ10/12/14/15
►16/18/20

Delos Scale

Delos Scale

Wide-band Voltage : AC80-250V ◀
Measurement accuracy: 0.005mm ◀
Accurate Display of Machining Dimensions ◀

QM-160

QM-160 Precise Flat nose pliers

►Super clamping force
►Precision and durability
►Famous brand

58 Precision combination pressure plate suit

58 Precision combination pressure plate suit

►Super clamping force
►Precision persistence
►German quality

G1-1

Gear type power feed

►Walk steadily
►Six gear shift
►High power motor
►Built-in clutch

Environmental protection

Environmental protection Protection cover

► Protecting workers'safety
► Protect the environment
►Beautiful

Integral drill chuck

Integral drill chuck

► Integral
► Automatic locking
► Size :Φ O.5~16mm

Machine tool isolator

Machine tool isolator

► Super Supporting Force
► Stable shock absorption
► Durable

MX-2HG (12)

Cooling system

► Delay cutter life
► Oil chip separation
► Large water yield

gk

PRESENT NINE CONSUMABLES TO SOLVE YOUR WORRIES

MX-2HG
Pull rod/1

Pull rod/1

2

Triangle belt

3

Synchronous be

4

Return spring

5

Locking bolt

6

Chip protection

7

Locking handle

8

Motor carbon brush

9

Brake pads

safety of electrical appliances

CHNT (1)

Using European Standard Cable
Main cable2.5MM², Control cablel 1.5MM²

Electrical components are Siemens And CHNT

CHNT (2)
CHNT (3)

Identification clear
Convenient maintenance

MX-4LW (1)
MX-4LW (2)
MX-4LW (3)
MX-4LW (4)
Electrical safety (1)

Earthing protection
Door s open and power will be cut off.
Press emergency stop Power cut off.

Electrical safety (2)

Power off switch

Electrical safety (3)

Master switch Power Indicator Lamp

Electrical safety (4)

Earthing protection

Electrical safety (5)

Emergency stop button

packing

logo
MX-4LW (1)

Steel belt fastener Wood packaging ,
Locking connection Firm tensile strength.
Free transportation in China
Undertaking transportation insurance.

Perfect after-sales service

Mechanical Parts and Electrical Appliances
Guaranteed for 12 Months


  • Previous:
  • Next:

  • Model MX-6HG
    Work Table 1372 x 330mm
    Max. Longitudinal Travel(X-axis) 1020mm
    Max. Vertical Travel(Y-axis) 400mm
    Max. Cross Travel(Z-axis) 380mm
    Guide rail form(X、Y、Z) ▲■■
    Distance from spindle to table 470mm
    Horsepower 5HP
    Voltage Three phase380V(or220V、415V、440V)
    Frequency 50/60
    Spindle Taper Type NT40
    Step Number (Low Range) (High Range) 16steps 70、110、180、270、600、975、1540、2310rpm 140、220、360、540、1200、1950、3080、5440rpm
    Spindle Quill Travel 120mm
    Quill Feed/Quill O.D. 0.04、0.08、0.15/85.725mm
    T-Slot Slot No.×Width×Pitch 3x 16x 65mm
    Ram Travel 600mm
    Machine Dimensions 1820x1700x2000
    Weight 1900kg

    Accessories

    ● X, Y, Z three-axis grating ruler
    ● X, Y direction mechanical tool feeder
    ● QH160 precision flat pliers
    ● 58-piece set of M12 combined pressure plate
    ● 12-piece set of high-precision R8 collet set
    ● Cooling system and water pan
    ● A set of powerful integrated drill chuck
    ● A set of environmentally friendly protective covers

    Random wearing parts (gift)

    ● Two pieces of milling head bolts
    ● One piece of milling head brake pad
    ● One piece of automatic knife spring
    ● One V-belt
    ● One synchronous belt
    ● One rod
    ● A set of anti-dandruff leather
    ● Workbench locking handle four pieces

    Special accessories

    ● Rotary table
    ● dividing head
    ● Parallel blocks
